Ironless rotor response
Low inertia windings reduce cogging and support repeatable low speed control in handheld medical tools and robotic end effectors.
EC motors, gearheads and controllers
maxon motor - compact brushless DC drive systems for certified motion axes
0.5 W to 1 kW ratings, 4 mm to 90 mm diameters, ironless rotor DC motors, EC-i and EC-flat platforms, planetary gearheads and EPOS positioning electronics.
4-90MMMotor diameter
1kWMAXCompact output
ISO13485Medical quality
AS9100Aerospace flowdown
engineering comparison
Motor platforms for high density motion design
Compare the two families most often specified when design teams need low cogging, high dynamic response and documented validation data.
ParameterEC-i brushless DCDCX ironless DC
Diameter range30 - 90 mm6 - 35 mm
Continuous output30 W - 750 W0.5 W - 150 W
Speed envelopeUp to 20,000 rpmUp to 25,000 rpm
Control pairingEPOS4 positioningESCON servo drive
Validation fitRobotics, pumps, prostheticsSurgical tools, optics, aerospace locks
why engineers specify maxon
Precise motion packages without uncontrolled sourcing risk
Gearhead matching
Planetary stages are paired by torque, bearing load and duty cycle, with ratios documented for thermal rise and acoustic limits.
Controller continuity
EPOS and ESCON drive data keeps current loops, encoder feedback and safety limits aligned from prototype to serial production.
Regulated documentation
ISO 13485, AS9100 and CE files support purchasing teams that need traceability, change notification and controlled component evidence.
70+YEARS MOTION ENGINEERING
120COUNTRIES SERVED
25MPRECISION DRIVES SHIPPED
380ACTIVE PATENTS
download hub
Data packages for specification review
CAD modelsSTEP, DXF and envelope drawings for EC-i and GPX assemblies.
DatasheetsTorque curves, winding data, speed constants and thermal resistance.
Validation filesQuality certificates, RoHS statements and regulatory production notes.
Selection notesApplication checklists for pump, robot joint and medical actuator duty cycles.
frequently checked
Specification answers before RFQ
Which maxon DC motor family fits low inertia positioning?
DCX ironless rotor motors are commonly reviewed first when the axis needs fast acceleration, smooth low speed behavior and compact diameter below 35 mm.
Can EC motors ship as motor, gearhead and controller sets?
Yes. The engineering review can combine EC-i or EC-flat motors with GPX gearheads, encoders and EPOS positioning controllers as one validated motion stack.
What documents are available for regulated devices?
Datasheets, production certificates, change notes and quality system evidence can be aligned with ISO 13485, AS9100 and CE machinery directive requirements.
Send the duty cycle, envelope and certification target.
Our specification team will return a motor, gearhead and controller path with torque margin, thermal assumptions and document requirements clearly marked.
Talk to a Spec Engineer
